Cable gland, IP68/IP69*, with strain relief, polyamide, M_ x 1.5 mm, with locknut, black
(*IP69 in conjunction with GEOS series empty enclosures and cabinets and Abox Pro series connection boxes)
Sealing range 11 - 21 mm, Thread length 11 mm
| Type of protection | IP68IP69 |
|---|
| Accessory colour | deep black |
|---|
| Width | 40 mm |
|---|---|
| Length | 40 mm |
| Height | 50 mm |
| Nominal size | M32 |
| Weight | 0.0308 kg |
| UV-resistant | yes |
|---|---|
| Halogen free | yes |
| Flammability class according with UL94 | V2 |
| Glow-wire flammability | 850 °C (EN 60695-2-11) |
| for sealing range min | 11 mm |
|---|---|
| for sealing range max | 21 mm |
| Torque | 8 Nm |
| Installation location | unprotected outdoor areas |
|---|
| EAN | 4013902932580 |
|---|---|
| ETIM Class | EC000441 |
| Custom tariff number | 39269097 |
| Minimum order quantity | 10 |
| Accessory material | Polyamide |
|---|
| EAN / GTIN | 4013902353705 |
|---|---|
| Width | 0.115 m |
| Weight | 0.308 kg |
| Height | 0.165 m |
| Quantity | 10 pieces |
| Depth | 0.083 m |
| EAN / GTIN | 4013902335558 |
|---|---|
| Width | 0.357 m |
| Weight | 2.063 kg |
| Height | 0.127 m |
| Quantity | 60 pieces |
| Depth | 0.257 m |
| EAN / GTIN | 4013902335565 |
|---|---|
| Width | 0.8 m |
| Weight | 240.804 kg |
| Height | 1.67 m |
| Quantity | 6480 pieces |
| Depth | 1.2 m |
| EAN / GTIN | 4013902932580 |
|---|---|
| Width | 0.04 m |
| Weight | 0.0308 kg |
| Height | 0.05 m |
| Quantity | 1 pieces |
| Depth | 0.04 m |
Tender text
(22703201.TXT 576 B)
Log in to download tender texts.
CAD-Data
(Download 3D-CAD-Data)
Log in to download tender texts.
Cable gland
KVR M20-MGM/sw
Productnumber 22702001
Sealing range 6 - 12 mm, Thread length 9 mm
Cable gland, IP68/IP69*, with strain relief, polyamide, M_ x 1.5 mm, with locknut, black
(*IP69...
Cable gland
KVR M20-GDB/MGM/sw
Productnumber 22702101
Sealing range 7 - 14 mm, Thread length 9 mm
Cable gland, IP68/IP69*, with strain relief, polyamide, M_ x 1.5 mm, with locknut, black
(*IP69...
Cable gland
KVR M25-MGM/sw
Productnumber 22702501
Sealing range 9 - 16 mm, Thread length 11 mm
Cable gland, IP68/IP69*, with strain relief, polyamide, M_ x 1.5 mm, with locknut, black
(*IP69...
Cable gland
