Description
Cable gland, IP68, with strain relief, polyamide, M_ x 1.5 mm, with locknut, orange
Sealing area 7 - 14 mm, thread length 9 mm
#22762101 | Dimensions: 26,5 x 26,5 x 36 mm
Cable gland
Technical Data
electrical characteristics
| Type of protection | IP68 |
|---|
Colours
| Accessory colour | reinorange |
|---|
Dimensions
| Width | 26.5 mm |
|---|---|
| Length | 26.5 mm |
| Height | 36 mm |
| Nominal size | M20 |
| Weight | 0.1022 kg |
Material characteristics
| UV-resistant | yes |
|---|---|
| Halogen free | yes |
| Flammability class according with UL94 | V2 |
| Glow-wire flammability | 850 °C (EN 60695-2-11) |
mechanical properties
| for sealing range min | 7 mm |
|---|---|
| for sealing range max | 14 mm |
| Torque | 5 Nm |
Ambient conditions
| Installation location | unprotected outdoor areas |
|---|
Sales Information
| ETIM Class | EC000441 |
|---|---|
| Custom tariff number | 39269097 |
Certificates
| Test mark | DNV (Class: Ships and Offshore Installations) |
|---|
Logistic data
Inner packaging
| EAN / GTIN | 4013902688227 |
|---|---|
| Width | 0.115 m |
| Weight | 3.097 kg |
| Height | 0.165 m |
| Quantity | 30 pieces |
| Depth | 0.083 m |
Outer packaging
| EAN / GTIN | 4013902688234 |
|---|---|
| Width | 0.357 m |
| Weight | 18.797 kg |
| Height | 0.127 m |
| Quantity | 180 pieces |
| Depth | 0.257 m |
Downloads
Download Data Sheet
Planningdata
Tender text
Tender text
(22762101.TXT 509 B)
Log in to download tender texts.
Similar products
Cable glandKVR M20-MGM/or
