Terminal block
Productnumber: 89643501 | Dimensions: 21 x 205 x 48 mm
Connecting terminal in accordance with DIN EN 60998 (VDE 0613), Ui=690V. For assembly in junction boxes Abox/Abox Pro from 2024 onwards.
raised screw terminal block for Abox/Abox Pro 250/350, 5-pole - 35 mm², In = 125 A, clampable cross-sections per pole: 12 x 10 mm², 8 x 16 mm², 4 x 25 mm², 4 x 35 mm² Cu rigid/flexible with wire-end ferrule
| Rated insulation voltage AC | 690 V |
|---|---|
| Rated insulation voltage DC | 690 V |
| Min. conductor cross section | 10 mm² |
| Rated current | 125 A |
| Terminal type | Screw terminal |
| Number of poles | 5 |
| Connection 1: Connection type | Screws |
| Connection 1: Strip length | 16 mm |
| Connection 1: Clamping points per pole | 4 |
| Connection 1: Suitable for Cu conductors | 1 |
| Connection 1: Connectable conductor cross-section, single-wire (min) | 10 mm² |
| Connection 1: Connectable conductor cross-section, single-wire (max) | 35 mm² |
| Base unit colour | grey |
|---|---|
| Cover colour | grey |
| Width | 21 mm |
|---|---|
| Length | 205 mm |
| Height | 48 mm |
| Glow-wire flammability according to EN 60695-2-11 | 960 °C |
|---|---|
| Industry quality | no |
| Connection 1: Tightening moment | 3.5 Nm |
|---|
| EAN | 4013902677368 |
|---|---|
| Packing Unit Code | C62 |
| ETIM Class | EC001284 |
| Custom tariff number | 85369010 |
| Insulating body material | Thermoplastic |
|---|
| CAD-Data | Download 3D-CAD-Data |
|---|
