STK-Z 4x16 STK-Z 4x16

#73000201 | Dimensions: 315 x 300 x 195 mm

Socket outlet combination

STK-Z 4x16

Socket outlet combination, protection class IP44, Additional enclosure for easy combination with STK socket combinations or AK Air distributors with flange openings (AK-F), including combination...

read more
Remember product

Description

Socket outlet combination, protection class IP44, Additional enclosure for easy combination with STK socket combinations or AK Air distributors with flange openings (AK-F), including combination flange AK3 KFL, without mounting flange

equipped with:

  • 4 x CEE plug socket outlet (on front) 16A, 400V

Highlights

The high-quality STK socket combinations are easily expandable via the AK Air flange system and offer high installation comfort with the central connection terminal for the supply line. Fully wired and tested with series connection devices and sockets. The STK-Z additional enclosures can be easily combined with the small distributors AK-F 14-56; a combination flange is included. The flexible system is also the basis for customer-specific solutions deviating from the standard. A product that offers flexibility and adapts to your needs.

Technical Data

Built-in devices

CEE plug socket outlet (on front) 16A, 400V 4

electrical characteristics

Rated operating voltage AC 400 V
Rated insulation voltage AC 400 V
Protection class II
Type of protection IP44
vented yes
Number of rows 0
Number of modules per row 0

Colours

Base unit colour grey
Cover colour grey

Dimensions

Width 315 mm
Length 300 mm
Height 195 mm
Inner width 295 mm
Inner height 106 mm
Weight 2.4 kg

Material characteristics

UV-resistant yes
Halogen free yes
Glow-wire flammability 850 °C (EN 60695-2-11)

mechanical properties

Type of fastening Wall mounting
Impact strength IK08
Sealable yes
Cover screw torque 1.2 Nm
Flange variant yes

Ambient conditions

max. relative humidity 25°C 90 %
max. relative humidity 40°C 50 %
Min. ambient temperature -25 °C
Max. ambient temperature 40 °C
24h ambient temperature 35 °C
Installation location protected outdoor areas

Sales Information

EAN 4013902689804
ETIM Class EC000379
Custom tariff number 85369095
Minimum order quantity 1

Material

Base unit material Polycarbonate, glass-fibre reinforced
Cover material Polycarbonate
Sealing material Polyurethane
Cover screw material Polyamide, glass-fibre reinforced
Hinged window material Polycarbonate

Logistic data

Outer packaging

EAN / GTIN 4013902689804
Width 0.335 m
Weight 2.7 kg
Height 0.27 m
Quantity 1 pieces
Depth 0.335 m

Pallet

EAN / GTIN 4013902689811
Width 0.8 m
Weight 184 kg
Height 1.74 m
Quantity 60 pieces
Depth 1.2 m

Downloads

Download Data Sheet

Download Data Sheet (73000201.pdf)

Handbook

Product manual DE pdf (8 MB)

Dimensioned drawing

Dimensional drawing pdf (2 MB)

Dimensional drawing dwg (2 MB)

Dimensional drawing dxf (12 MB)

Certificate

UKCA Declaration EN pdf (165 KB)

CE Declaration DE/EN/FR pdf (142 KB)

CE Declaration DE/EN/PL pdf (136 KB)

Planningdata

Tender text
